10mMax. Working Height
-
230kgPlatform Capacity
-
0.83mMachine Width
online message
If you are interested in our machine platforms or have any questions about how they work, then please get in touch using the following contact form.
Rotary screen bucket is specially designed to screen sand and gravel ,hard rock stones and washing sand underwater, and the efficiency of the rotary screen of the excavator is higher than that of the ordinary screen bucket; screen mesh hole specifications can be selected according to the size of the material(1-150mm), easy to replace, which greatly reduces the loss of machinery and the difficulty of operation. The screening hopper is suitable for screening various materials and has excellent mechanical properties.
l The mesh hole is not easy to block.
l Simple structure and convenient maintenance.
l The reliability of the whole machine is high, and the one-time investment is less.
l The screening cylinder can be rotated forward and backward for easy screening.
l The operation is stable and the noise is low.
l
Preliminary screening of waste materials, demolition, excavation and re-filling, and soil rebuilding of rocky land. The screening bucket is suitable for sorting natural materials before and after comminution, reducing the comminution time by 60%, so that materials that are compatible with the type of processing required can be recycled and managed. With the inching hydraulic system, even wet materials can be screened, increasing production by 30% year-on-year. It is suitable for gravel screening and beach cleaning in waterways. It is a good assistant for screening fine debris blocks. The size of the sorting screen can be adjusted by changing the screen. Screen sizes from 10mm to 150mm are available. Can be made according to customer needs.
The Yugong bucket comes equipped with an interchangeable mesh system around the drum inner circumference and replaceable sections in the conical rear area of the drum. Four models are offered to fit mini diggers from 6 tonne to 36 tonne excavator. Suittable for top-soil, quarried stone, remediation of contaminated soils beaches, demolition waste and green recycling duties. The MSB series is just at home clearing on a demolition site or in the quarry cleaning and sizing stone.
Model | MB-08 | MB-12 | MB-15 | MB-16 | MB-18 |
Length(mm) | 950 | 1380 | 1650 | 1850 | 2380 |
Width(mm) | 650 | 1050 | 1200 | 1490 | 1800 |
Height(mm) | 850 | 1280 | 1460 | 1860 | 2280 |
Screen Length(mm) | 610 | 680 | 720 | 980 | 1200 |
Screen Diameter(mm) | 540 | 780 | 1040 | 1360 | 1620 |
Oil pressure(mpa) | 10 | 12 | 12-15 | 15-23 | 22-25 |
Oil flow (L/min) | 20 | 45 | 56 | 63 | 63 |
Weight (kg) | 163 | 560 | 620 | 1590 | 2150 |
Machine class(T) | 2-5 | 6-12 | 12-20 | 20-26 | 26-36 |
